Radar Level Gauge NM700
Product Overview
The Radar Level Gauge NM700 Series is a high-performance non-contact radar level transmitter designed for continuous level measurement in tanks, vessels, silos, and storage containers operating under demanding industrial conditions.
Utilizing advanced microwave pulse radar technology, the NM700 provides accurate and reliable level measurement without contacting the measured medium. It is ideal for applications involving liquids, slurries, powders, and bulk solids, even in environments with significant temperature and pressure variations.
The NM700 adopts two-wire technology, making installation simple while reducing wiring costs. It also supports explosion-proof applications and offers a maximum measuring distance of 70 meters, making it suitable for a wide range of industrial process control applications.
Operating Principle
The Radar Level Gauge NM700 operates using microwave pulse radar technology.
The radar antenna continuously emits high-frequency microwave pulses toward the surface of the measured medium. The pulses are reflected back to the antenna, and the instrument calculates the distance by measuring the travel time of the reflected signal.
The measured distance is then converted into an accurate level value. Since the measurement is non-contact, the radar level gauge is not affected by changes in the physical properties of the medium, ensuring stable and reliable performance under harsh operating conditions.
Product Features
- Non-contact continuous level measurement
- Maximum measuring distance up to 70 m
- High measurement accuracy
- Two-wire technology
- Suitable for explosion-proof applications
- No bottom dead zone (blind zone)
- Easy installation
- Maintenance-free operation
- Durable industrial construction
- Fast refresh rate
- Digital LCD display
- Simple on-site calibration
- Software configuration and programming
- Supports HART communication
- Supports PROFIBUS-PA communication
- Supports FOUNDATION™ Fieldbus communication
- Suitable for high-temperature processes
- Excellent performance in harsh industrial environments
Product Advantages
TheRadar Level Gauge NM700 offers multiple advantages over traditional level measurement technologies:
- Excellent replacement for differential pressure transmitters
- Alternative to magnetic level gauges
- Alternative to RF admittance level instruments
- Alternative to magnetic flap level indicators
- Not affected by vacuum conditions
- Not affected by pressure fluctuations
- Not affected by temperature changes
- Not affected by gases, vapor, steam, or smoke
- High reliability under complex process conditions
- Low maintenance requirements
- Stable long-term operation
Application Media
The Radar Level Gauge NM700 is suitable for continuous non-contact level measurement of:
- Liquids
- Slurries
- Powders
- Granular materials
- Bulk solids
It is particularly suitable for applications involving:
- Large temperature variations
- High pressure changes
- Inert gases
- Volatile media
- Harsh industrial environments
Product Applications
The Radar Level Gauge NM700 Series is widely used in:
- Storage tanks
- Process vessels
- Silos
- Warehouses
- Chemical plants
- Petroleum industry
- Water treatment
- Power plants
- Food processing
- Pharmaceutical industry
- Mining
- Cement industry
- Bulk material handling
- Industrial process automation
Technical Specifications
Measurement Performance
| Parameter | Specification |
|---|---|
| Measuring Principle | Microwave Pulse Radar |
| Measurement Type | Non-contact Continuous Level Measurement |
| Maximum Measuring Distance | 70 m |
Process Capability
| Parameter | Specification |
|---|---|
| Standard Process Temperature | Up to 200°C |
| High-Temperature Version | Up to 350°C (with high-temperature extension antenna) |
Communication Protocols
The NM700 supports multiple industrial communication interfaces:
- HART®
- PROFIBUS-PA
- FOUNDATION™ Fieldbus
Installation
| Parameter | Specification |
|---|---|
| Wiring | Two-wire Technology |
| Calibration | Digital LCD Local Calibration |
| Configuration | Software Programming |
Environmental Performance
The NM700 Radar Level Gauge maintains stable measurement performance under:
- Vacuum conditions
- Pressure fluctuations
- Temperature changes
- Gas environments
- Steam
- Smoke
- Volatile media
The low-energy microwave beam operates safely within the industrial frequency range and can be installed in both metal and non-metal tanks or pipelines without causing harm to personnel or the environment.
Product Advantages for Industrial Applications
The Radar Level Gauge NM700 combines high-precision radar technology, non-contact measurement, two-wire installation, and advanced digital communication into a robust industrial instrument. Its ability to operate reliably under extreme process conditions makes it an ideal solution for modern industrial level measurement applications.
Typical Applications
The Radar Level Gauge NM700 is commonly installed in:
- Chemical storage tanks
- Oil storage tanks
- Water treatment reservoirs
- Bulk material silos
- Powder storage bins
- Process vessels
- Mixing tanks
- Wastewater treatment facilities
- Cement silos
- Industrial process tanks
Frequently Asked Questions (FAQ)
What is the maximum measuring distance of the NM700?
The NM700 Radar Level Gauge provides a maximum measuring range of 70 meters.
What media can the NM700 measure?
The NM700 is suitable for:
- Liquids
- Slurries
- Powders
- Granular materials
- Bulk solids
Is the radar measurement affected by temperature or pressure?
No. The radar measurement is largely unaffected by:
- Vacuum
- Pressure variations
- Temperature changes
- Gas
- Steam
- Smoke
- Volatile media
This ensures reliable measurement under demanding industrial conditions.
Does the NM700 support industrial communication protocols?
Yes. The NM700 supports:
- HART®
- PROFIBUS-PA
- FOUNDATION™ Fieldbus
Can the NM700 be used in high-temperature applications?
Yes. The standard version supports process temperatures up to 200°C, while models equipped with a high-temperature extension antenna can operate at temperatures up to 350°C.
Why Choose the NM700 Radar Level Gauge?
The NM700 Series Radar Level Gauge delivers precise, maintenance-free level measurement using advanced microwave pulse radar technology. With non-contact operation, up to 70 m measuring range, two-wire installation, explosion-proof capability, HART/PROFIBUS-PA/FOUNDATION™ Fieldbus communication, and reliable performance under extreme temperature and pressure conditions, it is an excellent solution for industrial storage tanks, silos, process vessels, and bulk material handling applications.
