Smart Electromagnetic Flow Meter NSC102 for Micro Flow Measurement
Specification
High-Precision Solution for Small Flow Rate Measurement
Product Overview
The Smart Electromagnetic Flow Meter NSC102 for Micro Flow Measurement is an intelligent flow measurement instrument specially designed for low flow rate conductive liquid applications. Based on the electromagnetic flow measurement principle, it detects the induced signal generated by conductive liquids passing through a magnetic field to achieve accurate flow measurement.
Compared with traditional mechanical flow meters, the smart electromagnetic flow meter has no moving mechanical parts, which reduces measurement errors caused by mechanical wear and improves long-term operating stability.
With its compact structure design, this micro flow electromagnetic flow meter is suitable for equipment with limited installation space and can be widely used in precision fluid control systems, industrial equipment, and automation applications requiring accurate flow monitoring.
Working Principle
The smart electromagnetic flow meter operates based on Faraday’s Law of Electromagnetic Induction.
When a conductive liquid flows through the magnetic field generated by the excitation system inside the sensor, the liquid acts as a conductor and generates an induced voltage signal related to the flow velocity.
The electrodes inside the sensor detect this voltage signal, and the intelligent transmitter processes the signal. Based on the pipe size parameters, the instrument calculates the corresponding volumetric flow rate.
Because the electromagnetic measuring principle does not require mechanical rotating components, the flow meter provides advantages such as low pressure loss and stable operation.
Product Features
1. Accurate Micro Flow Measurement
This model is specially designed for small flow rate measurement applications and provides accurate monitoring of low-flow conductive liquids.
Flow Range:
| Pipe Size | Flow Range |
|---|---|
| DN3 | 0.0051 ～ 0.2545 m³/h |
| DN6 | 0.0204 ～ 1.02 m³/h |
| DN8 | 0.0565 ～ 2.825 m³/h |
It is suitable for applications requiring precise control and monitoring of small liquid flow rates.
2. High Measurement Accuracy
Accuracy Class: 0.5
The meter provides stable and reliable flow measurement performance for industrial applications requiring accurate flow monitoring.
3. Multiple Power Supply Options
The instrument supports multiple power supply methods:
- AC220V
- DC24V
- 3.6V Lithium Battery
Different power options allow flexible installation according to different application environments.
4. Intelligent Display and Signal Output
The flow meter is equipped with an intelligent display interface for real-time flow data viewing.
Signal Output:
4-20mA
The standard analog output signal allows easy connection with PLC systems, industrial control systems, and automation equipment for monitoring and control.
5. Compact Structure Design
The product adopts a compact integrated structure, making it suitable for installation in limited spaces.
Dimensions:
- Height (H): 220 mm
- Length (L): 120 mm
- Width (D): 80 mm
The compact design makes it suitable for equipment integration and small pipeline systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Smart Electromagnetic Flow Meter |
| Measuring Principle | Electromagnetic Induction |
| Flow Range | DN3: 0.0051-0.2545 m³/h |
| DN6: 0.0204-1.02 m³/h | |
| DN8: 0.0565-2.825 m³/h | |
| Accuracy Class | Class 0.5 |
| Power Supply | AC220V / DC24V / 3.6V Lithium Battery |
| Nominal Pressure | 1.6 MPa |
| Signal Output | 4-20mA |
| Dimensions | H220mm × L120mm × D80mm |
Applications
The Smart Electromagnetic Flow Meter for Micro Flow Measurement is suitable for:
Precision Fluid Control Systems
Used for monitoring low flow rate conductive liquids in systems requiring accurate flow control.
Industrial Automation Equipment
Can be integrated into automated equipment as a flow detection unit, providing stable flow signals for control systems.
Chemical Liquid Monitoring
Suitable for measuring small flow rates of conductive chemical liquids.
Laboratory and Analysis Equipment
The compact design and micro flow measurement capability make it suitable for equipment requiring precise liquid flow control.
Why Choose the Smart Electromagnetic Flow Meter?
No Moving Parts, Reduced Maintenance
The electromagnetic measurement principle eliminates mechanical rotating components such as impellers or gears, reducing mechanical wear during long-term operation.
Low Pressure Loss
The simple flow channel design creates minimal resistance to the fluid, helping maintain stable system operation.
Stable and Reliable Flow Output
The instrument detects flow changes through electromagnetic induction and provides a standard 4-20mA output signal for easy system integration.
Flexible Power Supply Options
Supporting AC220V, DC24V, and 3.6V lithium battery power supply options, the meter can adapt to different installation environments.
Selection Notes
The electromagnetic flow meter is designed for measuring conductive liquids.
For non-conductive media, such as some types of oils and other liquids with insufficient electrical conductivity, the meter may not provide effective measurement.
Before selection, please confirm:
- Medium characteristics
- Required flow range
- Pipe size
- Operating pressure
- Installation conditions
Conclusion
The Smart Electromagnetic Flow Meter NSC102 for Micro Flow Measurement provides a reliable solution for applications requiring small flow measurement, high accuracy, compact installation, and stable signal output.
With its electromagnetic measuring principle, Class 0.5 accuracy, multiple power supply options, and 4-20mA output, it is an ideal choice for precision fluid monitoring in industrial automation equipment and small-flow conductive liquid applications.
