Adjustable Temperature Switch NC10 series | Mechanical Thermostat Switch

Brand：NOIKE-AH
Model：NC10

Specification

Product Overview

The Adjustable Temperature Switch NC10 is a mechanical temperature control device designed for reliable temperature monitoring and limit control in industrial systems. It utilizes liquid expansion sensing technology to actuate an internal micro switch when the preset temperature is reached, providing dependable switching for temperature protection and control.

Featuring a compact design with IP40 protection, the NC10 offers an adjustable temperature setting range of up to 210°C. The rotating micro switch design simplifies adjustment and installation while providing stable and repeatable temperature switching performance.

The NC10 is suitable for hydraulic, lubrication, and transmission systems where accurate temperature limit detection is required to monitor whether the medium temperature exceeds preset maximum or minimum values.

Product Features

Liquid expansion sensing technology
Adjustable temperature setting up to 210°C
Compact industrial design
IP40 protection rating
Rotatable micro switch for convenient adjustment
High switching accuracy
Low hysteresis
Simple structure for reliable operation
Easy installation
Suitable for industrial temperature control applications

Applications

Industries

Hydraulic Systems
Lubrication Systems
Transmission Equipment
Industrial Machinery
Process Equipment

Typical Applications

Hydraulic oil temperature monitoring
Lubrication system temperature control
Transmission temperature protection
Industrial equipment temperature monitoring
High and low temperature limit control

Technical Specifications

Adjustable Range (°C)	Hysteresis	Maximum Temperature (°C)	Serial Number
0–90	4 ± 1 K	130	90
40–210	9 ± 2 K	250	210

Why Choose the Adjustable Temperature Switch NC10 ?

Effective temperature control helps improve system reliability and protect industrial equipment from abnormal operating temperatures. The NC10 combines a proven liquid expansion sensing mechanism with a compact mechanical design to provide dependable temperature switching for industrial applications.

Adjustable Temperature Settings

The adjustable switching range allows users to configure the temperature set point according to different operating requirements.

Reliable Mechanical Operation

Liquid expansion technology directly actuates the internal micro switch, providing stable switching performance without requiring complex electronic components.

Compact and Easy to Install

The compact housing and rotatable micro switch design simplify installation and adjustment, making the switch suitable for a wide range of equipment.

High Precision with Low Hysteresis

Designed with high switching precision and low hysteresis to help maintain consistent temperature control performance.

Suitable for Industrial Temperature Protection

The NC10 is designed for monitoring temperature limits in hydraulic, lubrication, and transmission systems where dependable mechanical temperature switching is required.

Application Case

Temperature Monitoring for Industrial Hydraulic Oil Systems

In hydraulic power systems, maintaining oil temperature within the specified operating range is essential for reliable equipment performance. The NC10 Adjustable Temperature Switch can be installed on the hydraulic circuit to continuously monitor oil temperature and provide switching signals when the preset temperature is reached.

When the medium temperature reaches the selected switching point, the liquid expansion sensing element actuates the internal micro switch, generating a control signal. This signal can be connected to a PLC, relay, or control circuit to activate alarms, start cooling equipment, or stop machinery according to the system design.

With adjustable temperature ranges of 0–90°C and 40–210°C, the NC10 provides flexible temperature control for hydraulic systems, lubrication units, transmission equipment, and industrial machinery requiring reliable mechanical temperature limit monitoring.

Frequently Asked Questions (FAQ)

1. How does the temperature switch NC10 work?

The NC10 uses a liquid expansion sensing element to actuate an internal micro switch when the preset temperature is reached, generating a switching signal.

2. Is the switching temperature adjustable?

Yes. The NC10 provides adjustable temperature ranges depending on the selected model.

3. What temperature ranges are available?

Two adjustable ranges are available:

0–90°C
40–210°C

4. What industries is the NC10 suitable for?

It is suitable for hydraulic systems, lubrication systems, transmission equipment, industrial machinery, and other industrial temperature control applications.

5. What is the maximum operating temperature?

Depending on the selected model, the maximum allowable temperature is 130°C or 250°C.

6. What are the main advantages of the NC10?

The NC10 offers adjustable temperature settings, high precision, low hysteresis, a compact structure, and easy installation.

7. What protection rating does the switch provide?

The NC10 has an IP40 protection rating.

8. Can the NC10 be integrated into industrial control systems?

Yes. The switching output can be connected to relays, PLCs, or other industrial control systems for temperature monitoring and protection.
